Specification
• Power input 670 W
• Power output 370 W
• No-load speed 10.000 rpm
• Cutting depth 28 mm
• Grinding disc 0 100 mm
• Spindle Thread M 10
• Weight 1.9 kg

Specification
• Power input 2100 W
• Power output 1350 W
• No-load speed 8300 rpm
• Cutting depth 43 mm
• Grinding disc 0 180 mm
• Spindle Thread M14
• Weight 4.7 kg

Why Magnetic Core Dill ?
100% Faster
Speed and time savings are achieved due to the following factors. Firstly the annular cutter principle of only cutting material from the periphery of the hole as opposed to the twist drill which must cut the complete diameter of the hole. Secondly the benefit of two aggressive sharp angles per cutting edge help to achieve faster feed rates and lower cutting resistance.

30% More Productivity
• Because the annular cutter is any cutting material from the periphery ofthe hole.
• Less motor energy and driving power is required.
• The larger the drill diameter the greater the energy saving.

Longer lifetime
The annular cutters cutting edges do less work than the twist drill resulting in more holes between sharpening. Thick 6mm body together with special tooth geometry ensures high stability and reduces to a minimum the risk of breakage due to overloading.

Special Features
• Line lock out
• Safety Belt
• Carrying Case
• Powerful motor
• Superb service life
• Extremely light weight
